Be quiet! Pure Power 12 M 850W ATX 3.1, 80 Plus Gold Modular for PCIe 5.0 GPUs and GPUs with 6+2 pin connectors 12VHPWR Cable Included, Silent 120mm be quiet! Fan - BN505
Be quiet! Pure Power 12 M 850W ATX 3.1, 80 Plus Gold Modular for PCIe 5.0 GPUs and GPUs with 6+2 pin connectors 12VHPWR Cable Included, Silent 120mm be quiet! Fan - BN505
Marca: BEQUIET!
Referencia: BN505
Disponibilidad: Disponible USA entrega 7/14 dias

Precio Efectivo y tranferencia

$159,990

Precio Tarjeta

$171,189

Consulta por Este producto por WhatsApp aquí

Cantidad

  • Model: Pure Power 12 M 850W
  • Continuous power (W): 850
  • Peak power (W): 900
  • Form factor: Version 3.1
  • Form factor EPS 12V: Version 2.92
  • Topology: LLC + SR + DC/DC
  • Voltage (Vac): 100 - 240
  • Frequency (Hz): 50 - 60
  • Input current (A): 12 / 6
  • Power factor at 100% load: >0.98
  • Modern standby: Yes
  • Power consumption in standby (W): <0.1
  • Average life time (h / 25°C): >100,000
  • Operating temperature up to (°C): 40
  • Efficiency
    • 80 PLUS certification: Gold
    • Efficiency (%) at 230V, 2% load: 73.8
    • Efficiency (%) at 230V, 10% load: 87.1
    • Efficiency (%) at 230V, 20% load: 91.7
    • Efficiency (%) at 230V, 50% load: 93.2
    • Efficiency (%) at 230V, 100% load: 91.2
  • Fan and cooling technology
    • Fan: Silence-optimized be quiet! fan
    • Fan size (mm): 120
    • Bearing technology: Rifle
    • Motor technology: 4-pole fan motor
    • Max. fan speed (rpm): 2000
    • dB(A) at 10% load: 9.3
    • dB(A) at 20% load: 9.4
    • dB(A) at 50% load: 9.5
    • dB(A) at 100% load: 25.7
  • Output
    • Multi-rail operation (12V rails): 2
    • +3.3V (A): 22
    • +5V (A): 22
    • +12V1 (A): 40
    • +12V2 (A): 36
    • -12V (A): 0.3
    • +5Vsb (A): 3
    • Max. combined power 12V (W): 850
    • Max. combined power 12VHPWR (W): 600
    • Max. combined power 3.3V + 5V (W): 120
    • Hold-up time at 100% load (ms): 20.6
    • Hold-up time at 80% load (ms): 24.9
    • Power good signal (ms): 100 - 150
  • Cables and connectors
    • Modular cables: Yes
    • Sleeved cables: P24, 12V-2x6
    • Flat cables: P4+4, P8, PCIe, drives
    • Maximum cable length (cm): 95
    • Cable length to motherboard (cm): 55
    • No. of cables: 8
    • ATX-Motherboard (20+4-pin): 1
    • P4+4 (CPU): 1
    • P8 (CPU): 1
    • 12VHPWR cables: 1
    • PCI-e 6+2-pin (GPU): 4
    • SATA: 6
    • PATA: 2
  • Protection
    • OTP (over temperature protection): Yes
    • OCP (over current protection): Yes
    • OPP (over power protection): Yes
    • SCP (short circuit protection): Yes
    • OVP (over Voltage protection): Yes
    • UVP (under Voltage protection): Yes
    • SIP (Surge & Inrush protection): Yes
  • Safety certification
    • BSMI: Yes
    • CB: Yes
    • CCC: Yes
    • CE: Yes
    • cTUVus: Yes
    • CU: Yes
    • FCC: Yes
    • RCM: Yes
    • TÜV: Yes
    • UKCA: Yes
  • Environmental directives
    • Energy Star: 8.0
    • ErP: Yes
    • WEEE: Yes
    • RoHS: Yes
    • Triman: Yes
  • Scope of delivery
    • Screws: Yes
    • Cable ties: Yes
    • User manual languages: CN, DE, EN, ES, FR, JP, PL, RU, TW
  • Casing
    • Dimensions without cable (L x W x H), (mm): 160 x 150 x 86
    • Weight (kg): 1.85
    • Color: Black
  • Service
    • International hotline / free of charge: Yes / DE, FR, US
  • Logistics data
    • Article number: BN505
    • Dimensions, package (L x W x H), (mm): 284 x 220 x 100
    • Gross weight, package (kg): 3.1
    • Pieces per packaging unit: 4
    • Dimensions, shipping box (L x W x H), (mm): 426 x 298 x 243
    • Gross weight, shipping box (kg): 12.5
